Cair+

The Cair+ is a modern indoor air quality monitoring station engineered for workplace wellness, smart building certification, and HVAC integration. Designed to blend seamlessly into contemporary corporate, hospitality, and educational interiors, it continuously quantifies the key factors shaping cognitive function and physical comfort.

Measured Channels

7 Parameters

Primary Protocol

Wi-Fi

Cloud Sync

Active Real-Time

Request a Quote Compare System Technical Datasheet

CAIR PLUS

ENGINEERING HIGHLIGHTS

Engineered for continuous telemetry & high reliability.

The Cair+ architecture integrates discrete optical, chemical, and physical sensor elements with low-latency edge buffering for dependable operational performance.

Request System Consultation

Simultaneous 6-parameter continuous telemetry

Subtle ambient LED status ring for intuitive air health awareness

Seamless wall mounting with concealed wire routing

Building Management System (BMS) integration via MODBUS/API

Continuous streaming to DLE Air Intelligence platform

Low acoustic noise sampling mechanism

STANDARDS & CREDENTIALS

Engineered for Global Environmental Standards

Our environmental telemetry hardware is designed to simplify building compliance audits, ESG reporting, and automated HVAC integration.

Calibrated Baseline

Green Building

LEED v4.1 Compliant

Meets EQ Credit criteria for Enhanced Indoor Air Quality strategies & continuous particulate tracking.

Air Concept

WELL v2 Certified Ready

Aligned with Air Feature A01, A05, and A08 for multi-parameter real-time telemetry verification.

Ventilation Standard

ASHRAE 62.1 Compatible

Optimized for Demand-Controlled Ventilation (DCV) closed-loop HVAC actuation via BACnet & Modbus.

Continuous Monitoring

RESET Air Grade Ready

Hardware calibrated for accredited indoor air quality data feeds with cloud payload verification.

TELEMETRY CHANNELS

Monitored Environmental & Gas Parameters (7)

Real-time measurement channels active on the Cair+ baseline architecture.

PM2.5particulate

Fine inhalable particles with diameters 2.5 µm and smaller

Unit: µg/m³Optical / Laser Scattering

PM10particulate

Inhalable coarse particles with diameters 10 µm and smaller

Unit: µg/m³Optical / Laser Scattering

CO2gases

Carbon Dioxide concentration indicating ventilation efficacy

Unit: ppmNDIR

TVOCvocs

Total Volatile Organic Compounds off-gassing from building materials

Unit: mg/m³ / ppbPID

Temperatureenvironmental

Ambient dry-bulb thermal measurement

Unit: °CSolid-state Bandgap

Humidityenvironmental

Relative air moisture saturation percentage

Unit: % RHCapacitive Polymer

AQIderived

Standardized Air Quality Index computed from multiple criteria pollutants

Unit: Index (0-500)Algorithmic Aggregation

SENSING PHYSICS

Sensor Technology Principles

Educational overview of physical and optical sensing methodologies deployed across this platform.

Optical / Laser Scattering

Uses focused laser light scattering to detect discrete particle diameters and compute mass concentration per unit volume in real time.

NDIR (Non-Dispersive Infrared)

Measures gas absorption at specific infrared wavelengths for high-stability, drift-resistant carbon dioxide and methane quantification.

Metal Oxide Semiconductor (MOS)

Monitors electrical resistance changes in heated metal oxide surfaces upon contact with reducing or oxidizing gases for general indoor air quality trends.

Solid-State Environmental Sensing

Integrated semiconductor and capacitive sensors for high-accuracy thermal, relative humidity, pressure, and ambient illuminance data.

INTEGRATION ARCHITECTURE

Connectivity & Software Topology

Edge Data Transport

Supported physical and wireless interfaces

Wi-FiStandard Interface

Ethernet (RJ45)Standard Interface

RS-485 MODBUSStandard Interface

BLEStandard Interface

Encrypted TLS 1.3 edge-to-cloud transport architecture.

Software Platform Compatibility

Integrated digital control layers

Mobile AccessiOS & Android App

Web DashboardMulti-Site Web Portal

Cloud SyncDLE Cloud Telemetry

Enterprise APIREST & MQTT Streams

Fail-Safe Buffer: Non-volatile local flash99.9% Telemetry Target

TELEMETRY & CLOUD ECOSYSTEMv2.4 Ready

Real-time monitoring across web, mobile & facility displays.

Every sensor stream is instantly ingested into the DLE Cloud Platform, offering multi-tenant analytics, historical heatmaps, and zero-latency TV lobby displays.

dle-cloud.internal / telemetry / station-node-04

Live Edge Stream (0.5s)

Real-Time AQIGood Quality

28US AQI Standard

PM2.5

6.4 µg/m³

CO₂ Level

462 ppm

TVOC

0.08 mg/m³

Relative Humidity

48.2 %

24-Hour Particulate Concentration Trend

Continuous 1-minute averaged telemetry buffer

PM2.5 PM10

00:0006:0012:0018:00Now

REST API & MQTT Export

Automated PDF Compliance

Modbus & BACnet Gateway

SYSTEM ARCHITECTUREDLE Air Intelligence

Connecting physical sensing to autonomous optimization.

Every DLE monitoring device integrates directly into the DLE Air Intelligence platform, transforming raw telemetry into energy-efficient ventilation control and predictive facility health.

Sense

Transducer Ingestion

Optical laser scattering and dual-channel NDIR ambient sampling.

Connect

Edge Transport

Encrypted payload routing via RS-485 Modbus, Wi-Fi, 4G, and MQTT.

Understand

Contextual Analytics

Spatial heatmaps, dynamic baselines, and thermal load analysis.

Optimize

Closed-Loop Control

Demand-Controlled Ventilation (DCV) actuation and automated BMS control.

Platform Endpoints: iOS / Android Apps Multi-Site Web Portal REST / MQTT APIs

Continuous Telemetry Engine
