Ambient PM

The Ambient PM is an outdoor-rated environmental monitoring station engineered to quantify ambient particulate dispersion (PM1, PM2.5, PM10) alongside meteorological baseline indicators. Built for perimeter construction compliance, industrial fence lines, and urban environmental networks, it delivers continuous telemetry under challenging weather conditions.

Measured Channels

12 Parameters

Primary Protocol

4G / LTE Cellular

Cloud Sync

Active Real-Time

Request a Quote Compare System Technical Datasheet

AMBIENT PM

ENGINEERING HIGHLIGHTS

Engineered for continuous telemetry & high reliability.

The Ambient PM architecture integrates discrete optical, chemical, and physical sensor elements with low-latency edge buffering for dependable operational performance.

Request System Consultation

Outdoor weatherproof housing designed for continuous deployment

Laser particulate sensing with heated inlet options to reduce humidity distortion

Integrated meteorological sensor interfaces (Wind, Rain, Solar)

Multi-carrier cellular and Wi-Fi transmission options

Solar power compatibility with external battery storage

Automated sensor diagnostics and zero-drift compensation

STANDARDS & CREDENTIALS

Engineered for Global Environmental Standards

Our environmental telemetry hardware is designed to simplify building compliance audits, ESG reporting, and automated HVAC integration.

Calibrated Baseline

Green Building

LEED v4.1 Compliant

Meets EQ Credit criteria for Enhanced Indoor Air Quality strategies & continuous particulate tracking.

Air Concept

WELL v2 Certified Ready

Aligned with Air Feature A01, A05, and A08 for multi-parameter real-time telemetry verification.

Ventilation Standard

ASHRAE 62.1 Compatible

Optimized for Demand-Controlled Ventilation (DCV) closed-loop HVAC actuation via BACnet & Modbus.

Continuous Monitoring

RESET Air Grade Ready

Hardware calibrated for accredited indoor air quality data feeds with cloud payload verification.

TELEMETRY CHANNELS

Monitored Environmental & Gas Parameters (12)

Real-time measurement channels active on the Ambient PM baseline architecture.

PM1.0particulate

Ultra-fine particulate matter with diameter less than 1.0 µm

Unit: µg/m³Optical / Laser Scattering

PM2.5particulate

Fine inhalable particles with diameters 2.5 µm and smaller

Unit: µg/m³Optical / Laser Scattering

PM10particulate

Inhalable coarse particles with diameters 10 µm and smaller

Unit: µg/m³Optical / Laser Scattering

Temperatureenvironmental

Ambient dry-bulb thermal measurement

Unit: °CSolid-state Bandgap

Humidityenvironmental

Relative air moisture saturation percentage

Unit: % RHCapacitive Polymer

Noise Levelenvironmental

Acoustic sound pressure level monitoring

Unit: dBAMEMS Acoustic Sensor

Illuminanceenvironmental

Ambient luminous flux per unit area

Unit: LuxPhotodiode Array

UV Indexenvironmental

Solar ultraviolet radiation risk rating

Unit: Index (0-11+)Photodiode UV Sensor

Wind Speedenvironmental

Horizontal ambient air velocity

Unit: m/sUltrasonic / Cup Anemometer

Wind Directionenvironmental

Vector direction of prevailing air movement

Unit: Degrees (°)Ultrasonic / Vane

Rainfallenvironmental

Precipitation accumulation rate and volume

Unit: mm/hTipping Bucket / Optical

AQIderived

Standardized Air Quality Index computed from multiple criteria pollutants

Unit: Index (0-500)Algorithmic Aggregation

SENSING PHYSICS

Sensor Technology Principles

Educational overview of physical and optical sensing methodologies deployed across this platform.

Optical / Laser Scattering

Uses focused laser light scattering to detect discrete particle diameters and compute mass concentration per unit volume in real time.

Solid-State Environmental Sensing

Integrated semiconductor and capacitive sensors for high-accuracy thermal, relative humidity, pressure, and ambient illuminance data.

INTEGRATION ARCHITECTURE

Connectivity & Software Topology

Edge Data Transport

Supported physical and wireless interfaces

4G / LTE CellularStandard Interface

Wi-FiStandard Interface

RS-485 MODBUSStandard Interface

LoRaWAN (Optional)Standard Interface

Encrypted TLS 1.3 edge-to-cloud transport architecture.

Software Platform Compatibility

Integrated digital control layers

Mobile AccessiOS & Android App

Web DashboardMulti-Site Web Portal

Cloud SyncDLE Cloud Telemetry

Enterprise APIREST & MQTT Streams

Fail-Safe Buffer: Non-volatile local flash99.9% Telemetry Target

TELEMETRY & CLOUD ECOSYSTEMv2.4 Ready

Real-time monitoring across web, mobile & facility displays.

Every sensor stream is instantly ingested into the DLE Cloud Platform, offering multi-tenant analytics, historical heatmaps, and zero-latency TV lobby displays.

dle-cloud.internal / telemetry / station-node-04

Live Edge Stream (0.5s)

Real-Time AQIGood Quality

28US AQI Standard

PM2.5

6.4 µg/m³

CO₂ Level

462 ppm

TVOC

0.08 mg/m³

Relative Humidity

48.2 %

24-Hour Particulate Concentration Trend

Continuous 1-minute averaged telemetry buffer

PM2.5 PM10

00:0006:0012:0018:00Now

REST API & MQTT Export

Automated PDF Compliance

Modbus & BACnet Gateway

SYSTEM ARCHITECTUREDLE Air Intelligence

Connecting physical sensing to autonomous optimization.

Every DLE monitoring device integrates directly into the DLE Air Intelligence platform, transforming raw telemetry into energy-efficient ventilation control and predictive facility health.

Sense

Transducer Ingestion

Optical laser scattering and dual-channel NDIR ambient sampling.

Connect

Edge Transport

Encrypted payload routing via RS-485 Modbus, Wi-Fi, 4G, and MQTT.

Understand

Contextual Analytics

Spatial heatmaps, dynamic baselines, and thermal load analysis.

Optimize

Closed-Loop Control

Demand-Controlled Ventilation (DCV) actuation and automated BMS control.

Platform Endpoints: iOS / Android Apps Multi-Site Web Portal REST / MQTT APIs

Continuous Telemetry Engine
